avantifred 0 Report post Posted December 27, 2008 Have a '64 R2 ...no AC.... How do I remove the Radio from the dash. There is NO info in the shop book Quote Share this post Link to post Share on other sites
Regnalbob 0 Report post Posted December 28, 2008 Have a '64 R2 ...no AC.... How do I remove the Radio from the dash. There is NO info in the shop book DISCONNECT the battery. You will need to remove the passenger side panel (carpeted) of the console to help with the removal. Remove the bolt holding the radio to the "Z" bar and the antenna lead and the connector for the speaker and power. Pull the knobs off and remove the hex nuts from the control bushings. You should now be able to remove the radio by working it out through the open side of the console. Bob Quote Share this post Link to post Share on other sites
avantifred 0 Report post Posted December 29, 2008 DISCONNECT the battery. You will need to remove the passenger side panel (carpeted) of the console to help with the removal. Remove the bolt holding the radio to the "Z" bar and the antenna lead and the connector for the speaker and power. Pull the knobs off and remove the hex nuts from the control bushings. You should now be able to remove the radio by working it out through the open side of the console.Bob Thanks for the reply Bob, I'll try it as soon as my back recovers from todays under dash work on the heater core installation with all new hoses & gaskets ! Thanks again & Happy new year, Fred Quote Share this post Link to post Share on other sites
